RIELLO S3T CPT 10 SENTRYUM UPS 10000 VA
VERSION WITH INTERNAL BATTERIES
AUTONOMY UP TO 10 MINUTES
INPUT
Rated Voltage: 380 / 400 / 415V three-phase + N
Rated frequency: 50/60 Hz
Frequency tolerance: 40 ÷ 72 Hz
Power factor at full load: 0.99
BY-PASS
Rated Voltage: 380 / 400 / 415V three-phase + N
Number of phases: 3 + N
Voltage tolerance: 180 ÷ 264 V (selectable)
Rated frequency: 50 or 60 Hz (selectable)
Frequency tolerance: ±5 (selectable)
EXIT
Rated power: 10 kVA
Active power: 10 kW
Number of phases: 3 + N
Static stability: ± 1%
Crest factor: 3 : 1 Ipeak/Irms
Voltage distortion: ≤ 1% with linear load / ≤ 3% with distorting load
Frequency: 50/60 Hz
Frequency stability in battery: 0.01%
Overload: 125% for 10 min - 150% for 1 min - 200% for 0.5 sec
BATTERIES
Type: VRLA AGM/GEL/NiCd/Li-ion/Supercaps
Depth: 840 mm
Width: 280 mm
Height: 700 mm
Weight (kg): 48
- Phase
- Three phase
- Frequency (Hz)
- 50 / 60
- Voltage (V)
- 380-400-415 + N
- Protection degree
- IP20
- Power (VA)
- 10000
- Battery type
- AGM/GEL/NiCd/Li-ion/Supercaps
- Operating temperature (°C)
- 0 °C / +40 °C
- Running time (h)
- 11 min
- Acoustic pressure
- 40 dB(A) 1 mt.
- Length (mm)
- 840
- Width (mm)
- 280
- Height (mm)
- 700
- Dry weight (Kg)
- 48
- Colour
- Grey
