0
Phase type: Single-phase
Voltage: 230 V
Frequency: 50/60 Hz
Power: 450 W
Battery voltage: 6/12/24 V
Charging capacity: 35-225 Ah
Charging positions: 3
Regulation of current: 6V 7A - 12V 10A - Boost 15A
Fuse: 30 A
Length: 210 mm
Width: 360 mm
Height: 140 mm
Weight: 8,5 kg
SOS RECOVERY function: Yes
The GYS BATTERY CHARGER GYSFLASH INVERTER 12V is a state-of-the-art device,
designed to meet all charging and maintenance needs of 12V lead-acid batteries.
Thanks to its inverter technology and 5 built-in functions, this charger stands out for its versatility,
ease of use and high performance.
5 key functions for a top-performing battery:
Charging: Fast and safe battery charging, thanks to an advanced charging curve that adapts voltage and current according to the state of the battery.
Diagnosis: Assesses the health of the battery and identifies any problems, such as sulphation or defective cells.
Showroom: Keeps a vehicle's battery on show at its maximum charge level at all times, guaranteeing an immediate start.
Battery change: Compensates for absorption peaks during battery change, preserving the memories of the vehicle's electronic devices.
Stabilised power supply: Provides stable voltage and current, ideal for powering electronic devices during maintenance or repair.
Distinctive features:
Intuitive and multilingual: The interface is easy to use and the display is available in 19 languages.
Compact and versatile: Its small size and low height allow it to be easily positioned under the vehicle.
Safe and reliable: Multiple protections and cooling system ensure safe use and prolong product life.
Advanced functions: Automatic restart, cable calibration, showroom mode, customisable charging curve and automatic recovery of sulphated batteries.
Flexible: Can be used with batteries from 10 to 600 Ah and adapts to different cable types.
Technical specifications GYS GYSFLASH INVERTER 12V BATTERY CHARGER:
Model: GYSFLASH 50.12 HF FV
Power supply: 85 > 265 V, 50/60 Hz
Power consumption: 850
Maximum charging current: 50 A
Battery voltage: 12 V
Battery capacity: 10-600 Ah
Degree of protection: IP21
Dimensions: 30 x 29.2 x 10.5 cm
Weight: 6.5 kg
Charging curve: IU0 I0 U
BSU:
Charging voltage: 13.5V - 14.8V
Trickle voltage: 12.9 V
Holding current: 80 A
If you are looking for another product similar to the GYS BATTERY CHARGER GYSFLASH INVERTER 12V portable charger,
then we recommend that you take a look at the entire range dedicated to battery chargers.
Images and technical data are not binding.
Phase type: Single-phase
Voltage: 230 V
Frequency: 50/60 Hz
Power: 450 W
Battery voltage: 6/12/24 V
Charging capacity: 35-225 Ah
Charging positions: 3
Regulation of current: 6V 7A - 12V 10A - Boost 15A
Fuse: 30 A
Length: 210 mm
Width: 360 mm
Height: 140 mm
Weight: 8,5 kg
SOS RECOVERY function: Yes
