CUMMINS C1250D5AB Generator Set Three-phase 1250KVA Silenced Diesel

CUMMINS C1250D5AB Generator Set Three-phase 1250KVA Silenced Diesel

The CUMMINS C1250D5AB is a powerful three-phase electric generator designed to provide reliable and continuous power in large industrial and commercial applications. Thanks to its Cummins engine, this genset provides high performance and a long service life.

Key features:

Power: With a maximum output of 1250 kVA and a continuous output of 1125 kVA, this generator is capable of powering a wide range of electrical equipment, even under high load conditions.
Engine: Equipped with a robust Cummins KTA38-G9 diesel engine, synonymous with reliability and durability.
Voltage and frequency: Provides a voltage of 380-440 V and a frequency of 50 Hz, suitable for most industrial and commercial applications.
Dimensions and weight: With dimensions of 7136.6 mm x 2174.6 mm x 2447 mm and a dry weight of 12673 kg, this generator is of considerable size but offers high power.
Consumption: The fuel consumption is 196 litres per hour at 75% load, which is in line with the generator's performance.
Quietness: Thanks to the soundproofing system, the noise level is reduced, ensuring comfortable operation.
Electric start: The electric start makes starting the generator quick and easy.
Electronic speed regulator: Ensures precise frequency and voltage regulation.
Alternator: The S6G alternator guarantees high-quality power production.

Technical characteristics CUMMINS C1250D5AB:

Phase type: Three-phase
Continuous Power: 1125 KVA / 900 KW
Maximum Power: 1250 KVA / 1000 KW
Engine: Cummins KTA38-G9
Power supply: Diesel
Engine RPM: 1500 rpm
Starter: Electric
Speed Governor: Electronic
Voltage: 380-440 V
Frequency: 50 Hz
Consumption at 75 % load: 196 l/h
Length: 7136.6 mm
Width: 2174.6 mm
Height: 2447 mm
Dry weight: 12673 kg
Alternator: S6G

If you are looking for a product CUMMINS C1250D5AB with similar characteristics CLICK HERE.

Images and data purely indicative.
