WHISPER W-SQ 22,5 MOBILE GENERATOR 22KW SINGLE-PHASE AVR

  • New
whisper w sq 225 mobile generator 22kw single phase avr
search
  • whisper w sq 225 mobile generator 22kw single phase avr
  • whisper w sq 225 mobile generator 22kw single phase avr
  • whisper w sq 225 mobile generator 22kw single phase avr
  • whisper w sq 225 mobile generator 22kw single phase avr
  • whisper w sq 225 mobile generator 22kw single phase avr
WHISPER POWER
41101220
New product

Phase Type: Single Phase
Maximum Power: 24.7 KVA / 22 KW
Continuous Power: 22.5 KVA / 20 KW
Fuel: Diesel
Voltage: 230 V
Frequency: 50 Hz (60 Hz)
Engine: Mitsubishi S4S - 4 Cylinders
Emissions standard: Not Emissions
Number of cylinders: 4
Engine speed: 1500/1800 rpm
Acoustic power: 58 dBA
Voltage regulator: AVR
Length: 1260 mm
Depth: 680 mm
Height: 800 mm
Net weight: 580 Kg

Technical features
Phase
Single phase
Maximum power single phase (KW)
22
Continuous power single phase (KW)
20
Maximum power single phase (KVA)
24.75
Continuous power single phase (KVA)
22.5
Fuel
Diesel
Frequency (Hz)
50 (60 on request)
Voltage (V)
230
Engine
Mitsubishi S4S
Emissions Regulations
Not Emitted
Engine rpm (rpm)
1500/1800
Number cylinders
4
Cooling
Indirect
Acoustic pressure
58 dB(A)
Length (mm)
1260
Width (mm)
680
Height (mm)
800
Dry weight (Kg)
580
Silenced
Yes
Super silenced
Yes
Product type
Generator
Voltage regulator
AVR
Engine manufacturer
Mitsubishi
Details

WHISPER W-SQ 22,5 MOBILE GENERATOR 22KW SINGLE-PHASE AVR

WHISPER W-SQ 22,5 Single-phase mobile generator with diesel-powered Mitsubishi S4S engine, delivers a power of 22KW, complete with AVR voltage regulator.

The WHISPER W-SQ 22,5 vehicle generator is designed for use in the vehicle. equipped as standard with a robust acoustic enclosure with anti-corrosion metal plating and heavy insulation material for optimal sound reduction. Hearing protection is a must. equipped with easy access to all sides of the generator and offers access to all maintenance-related components from one side only.

Thanks to the AVR technology electrical stabilizer that works at very low distortion, WHISPER W-SQ 22.5 delivers constant current loads without voltage peaks that could damage electrical and electronic devices. Another advantage of the inverter is; that of working with variable engine revolutions, based on the need; of current to be supplied, optimizing fuel consumption, gas emissions and wear of mechanical parts.

AVR VOLTAGE REGULATOR

WHISPER W-SQ 22,5  equipped with AVR which, mounted on an alternator, allows a generator set or current generator to stabilize the output voltage and does not damage the connected sensitive electronic devices. In the modern market, inverters have made a huge step forward in terms of technology and performance; for this reason the best brands of generator sets and alternators in the world are moving along this line of thought.

Technical characteristics WHISPER W-SQ 22,5:

Phase Type: Single Phase
Maximum Power: 24.7 KVA / 22 KW
Continuous Power: 22.5 KVA / 20 KW
Fuel: Diesel
Voltage: 230 V
Frequency: 50 Hz (60 Hz)
Engine: Mitsubishi S4S - 4 Cylinders
Emissions standard: Not Emissions
Number of cylinders: 4
Engine speed: 1500/1800 rpm
Acoustic power: 58 dBA
Voltage regulator: AVR
Length: 1260 mm
Depth: 680 mm
Height: 800 mm
Net weight: 580 Kg

Are you looking for a product with different technical characteristics? HERE you can find the area dedicated to WHISPER vehicle generators or those of other specialized brands.

Images and non-binding technical data.
