MOSA GE 13000 HBS

MOSA GE 13000 HBS 9,2 KW AVR genset

MOSA GE 13000 HBS is a single and three-phase 9,2 KW gasoline-powered generator set with Honda engine and voltage regulator with AVR technology. The MOSA GE 13000 HBS is easily transportable thanks to the side handles.
The MOSA GE 13000 HBS generator set delivers a stable and precise three-phase power of 9.2 KW suitable for powering sophisticated electronic equipment that is sensitive to voltage and frequency variations.
It is therefore possible to enjoy quietly and easily all the small comforts of home wherever you are: lights, fans, a coffee machine, laptops, radio or TV.
The MOSA GE 13000 HBS generator set is equipped with a 25-liter capacity tank for an autonomy of 10 hours of continuous operation at 75% load.

Oil Alert
The ''Oil Alert''system is designed to prevent engine damage caused by insufficient oil in the sump.
This system automatically shuts down the engine, before the oil level falls below the safety limit.

The MOSA GE 13000 HBS generator set control panel houses the machine's outlets and controls, including the circuit breaker, residual current device, hour meter and voltmeter. The recessed front is specially designed to protect the outlets.
The MOSA GE 13000 HBS generator set is suitable for a wide range of uses such as construction, equipment rental, events.

Technical features of the MOSA GE 13000 HBS:

Three-phase Stand-by (LTP) output: 13 kVA (10.4 kW) / 400V / 18.7 A
Three-phase PRP output: 11.5 kVA (9.2 kW) / 400V / 16.6 A
Single-phase PRP output 6 kVA / 230V / 26 A
Frequency: 50 Hz
Cos ϕ: 0.9

MOTOR TECHNICAL DATA
Model: HONDA GX 630
Net stand-by output: 14.5 kWm (19.7 hp)
Net PRP output: 10.5 kWm (14.3 hp )
Cylinders / Displacement: 2 / 688 cm³
Bore / Stroke: 78 / 72 (mm)
Compression ratio: 9. 3 : 1
RPM controller: Mechanical
110 % (Stand-by power): 6.25 lt./h
100 % PRP: 5.25 lt./h
75 % PRP: 3.9 lt. /h
50 % of PRP: 2.6 lt./h
Oil capacity in sump: 1.9 lt.
Electrical system: 12 Vdc (AE)
Battery charge alternating capacity: 20 A

TECHNICAL DATA ALTERNATOR
Continuous power: 11.5 kVA
Standby power: 12.5 kVA
Single-phase voltage: 380 - 415 Vac
Frequency: 50 Hz
Cos ϕ: 0. 8
Voltage regulation accuracy: ± 1 %
Sustained short circuit current: 3 In
Transient Cdt (100% load): < 15 %
Efficiency at 100% load: 83. 5 % (230V - Cos ϕ 0.8)
Isolation: Class H
Connection - Terminals: Series - No. 6
Harmonic Distortion - THD: < 4 %
Direct Synchronous - Xd: 239 %
Direct Transit - X'd: 19 %
Direct Subtransit - X "d: 4.6 %
Quad Synchronous. - Xq: 130 %
Transitory - T'd: 0.046 sec
Subtransitory - T "d: 0.006 sec
Unloaded - T'do: 0. 58 sec
Protection Class: IP 23
Cooling Air Flow: 0.082 m³/sec.
Coupling - Bearings: Direct J609b - No. 1
Model A.V.R. HVR 10

GENERAL SPECIFICATIONS
Tank capacity: 25 lt.
Run time (75% of PRP): 10. 4 h
Starting battery 12 Vdc -18Ah (AE)
Measured acoustic power LwA: 96 dB(A) (71 dB(A) @ 7m)
Guaranteed acoustic power LwA: 96 dB(A) (71 dB(A) @ 7m)
Performance class: G2
Length: 935 mm
Width: 525 mm
Height: 645 mm
Weight: 142 kg

If you are looking for another product such as MOSA GE 13000 HBS generator set then you can browse our catalog for more land based generator sets.

Images and technical data are not binding.
