FIRMAN SDG30FS GENERATOR 33KVA THREE-PHASE SUPER SILENT

  • New
firman sdg30fs generator 33kva three phase super silent
search
  • firman sdg30fs generator 33kva three phase super silent
  • firman sdg30fs generator 33kva three phase super silent
  • firman sdg30fs generator 33kva three phase super silent
NO BRAND
SDG30FS
New product

Phase type: Three-phase
Continuous power: 30 KVA / 24 KW
Maximum power: 33 KVA / 26 KW
Engine: FIRMAN FD4100DY
Power supply: Diesel
Engine speed: 1500 rpm
Regulation of revolutions: Mechanical
Emissions standard: Stage Zero
Starter: Electric
Voltage regulator: Compound
Voltage: 400 V
Frequency: 50 Hz
Socket panel: Terminal box
Tank capacity: 65 l
Consumption at 75% of the load: 5.69 l/h
Autonomy at 75% of the load: 11.45 h
Length: 2050 mm
Width: 750 mm
Height: 1090 mm
Net weight: 820 kg

Technical features
Phase
Three phase
Maximum power three phase (KW)
26
Continuous power three phase (KW)
24
Maximum power three phase (KVA)
33
Continuous power three phase (KVA)
30
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
400
Engine
FIRMAN FD4100DY
Emissions Regulations
Stage Zero
Engine rpm (rpm)
1500
Speed governor
Mechanical
Starting system
Electric
Number cylinders
4
Cylinders' position
In line
Fuel tank capacity (L)
65
Consumption (L/h)
5.69 at 75% of load
Running time (h)
11.45 at 75% of load
Length (mm)
2050
Width (mm)
750
Height (mm)
1090
Dry weight (Kg)
820
Silenced
Yes
Super silenced
Yes
ATS Switch device
No
Voltage regulator
Compound
Engine manufacturer
FIRMAN
Details

FIRMAN SDG30FS GENERATOR 33KVA THREE-PHASE SUPER SILENT

The FIRMAN SDG30FS three-phase generating set is equipped with a FIRMAN FD4100DY diesel-powered engine, capable of delivering a power of 33KVA complete with a Compound voltage regulator and automatic control panel.

This generator is equipped with electric, manual or automatic start with a 12 V battery, and is equipped with a FIRMAN HGM4020N control unit which allows you to view all the electrical parameters of the engine and generator, of the functions, status of the generating set, managing the entire group and displaying, if any, system errors or alarms. The groupset has low fuel consumption, in fact it consumes only 5.6 litres/hour at 75% of the load, combined with a large tank of 65 liters of maximum capacity, it will give you an autonomy of around 11 hours.

This group is equipped with a soundproofed cabin, made of 20/10 thick carbon steel, folded and electro-welded, with protection class IP23 and which can be opened in two sections. This cabin allows an incredible reduction of noise pollution, to the point of making it supersilenced. The generator set guarantees efficient and silent operation thanks to the FIRMAN FD490DY engine, which allows for the delivery of a maximum power of 33KVA.

TECHNICAL FEATURES FIRMAN SDG30FS:

Phase type: Three-phase
Continuous power: 30 KVA / 24 KW
Maximum power: 33 KVA / 26 KW
Engine: FIRMAN FD4100DY
Power supply: Diesel
Engine speed: 1500 rpm
Regulation of revolutions: Mechanical
Emissions standard: Stage Zero
Starter: Electric
Voltage regulator: Compound
Voltage: 400 V
Frequency: 50 Hz
Socket panel: Terminal box
Tank capacity: 65 l
Consumption at 75% of the load: 5.69 l/h
Autonomy at 75% of the load: 11.45 h
Length: 2050 mm
Width: 750 mm
Height: 1090 mm
Net weight: 820 kg

Are you looking for a generator set with different technical characteristics? HERE you can find the area dedicated to FIRMAN generator sets or other specialized brands.

Non-binding images and technical data.

Technical Sheet / Manuals
Related Accessories
List price
14.640,00 € tax incl.
12.000,00 € tax excl.
Discounted Price
8.637,60 € tax incl.
7.080,00 € tax excl.
