Product Type: Industrial Generator Set
Continuous power (PRP): 150.0 (kVA)
Continuous power (PRP): 120.0 (kW)
Stand-by power (LTP): 165.0 (kVA)
Stand-by power (LTP): 132.0 (kW)
Voltage: 400V
Frequency: 50 Hz
Power factor: 0.8 cosφ
Sound pressure level at 7 m: 78.0 dBA
MOTOR
Motor brand: BAUDOUIN
Engine model: 6M11G165/5
Fuel: Diesel
Number of cylinders: 6
RPM: 1500 r.p.m.
Displacement: 6.75 l
Aspiration: Turbo
Standard voltage: 12 V
Consumption at 100% (L.T.P.): 36.1 l/h
Consumption at 100% (P.R.P.): 32.7 l/h
Consumption at 75% (P.R.P.): 24.5 l/h
Consumption at 50% (P.R.P.): 16.7 l/h
Consumption at 25% (P.R.P.): 9.3 l/h
DIMENSIONS AND WEIGHT
Width: 1150 mm
Length: 2944 mm
Height: 1870 mm
Dry weight: 1870 Kg
The VISA BD150CK silenced land-based generator set, rated at 150 KVA in continuous use and AVR, mounts top brand components: the VISA BD150CK model uses a reliable BAUDOUIN 6M11G165/5 4-cylinder, 1500-rpm diesel engine and a STAMFORD UCI274F alternator equipped with AVR AS440 with 1% voltage regulation accuracy.
The VISA CRICKET industrial power generators feature silenced casings and tropicalized treatment, thus they are suitable for use in hot climates; in particular the VISA BD150CK is water-cooled, which guarantees excellent heat management.
The sturdy frame of the silenced generator set VISA BD150CK contains a capacious tank of 280 liters, which guarantee an autonomy of more than 10 hours at 75% load; moreover the dimensions of this generator are optimized for its transport by truck and its storage on a 40' HC container.
Main advantages of choosing a VISA BD150CK industrial generator set
1 - Original industrial diesel engine with certificate of origin
2 - Brushless industrial alternator with AVR
3 - Steel basement, tank with electro level
4 - Soundproofing hood completely made of galvanized sheet metal and painted with polyester powders
5 - Soundproofing material made of polyester fiber with high abatement
6 - Residential exhaust silencer with insulated manifold
7 - Electrical panel mounted on board the machine with control device and protection device integrated in the box
8 - Compactness for easy handling and use
9 - Test certification, manuals and diagrams supplied
10 - World wide after sales technical assistance support
11- CRICKET RANGE: FROM 9 TO 200 kVA at 50 or 60Hz.
1 - On/off key;
2 - Emergency stop button;
3 - DEEP SEA® 4520 MKII control unit;
4 - Main switch of primary brand.
DEEP SEA® 4520 MKII
DSE4520 control panel is a compact automatic power failure control module. By monitoring a large number of motor parameters, the module is able to display warning, shutdown and motor status information on the backlit LCD display.
This control unit allows the CK 100 generator set to be combined with a mains/group switching for automatic starting.
Images and technical data are not binding
