TECNOGEN H2700

TECNOGEN LD7500TE
search
  • TECNOGEN LD7500TE
  • TECNOGEN LD7500TE
  • TECNOGEN LD7500TE
TECNOGEN
LD 7500 TE
New product

Maximum three-phase power: 5.9 KW
Maximum three-phase power: 7.3 KVA
Fuel: Diesel
Voltage: 400 - 230 V
Engine: Kohler 15LD440
Start: Electric
Length: 780 mm
Width: 520 mm
Height: 560 mm
Weight: 106 Kg

STANDARD EQUIPMENT

Protective frame

Oil level sensor

Exhaust gas silencer

Air filter

Fuel tank

Output sockets with thermal protection or circuit breaker

12V battery for models with electric start

Technical features
Phase
Single phase / Three phase
Maximum power single phase (KW)
3.1
Maximum power single phase (KVA)
3.8
Maximum power three phase (KW)
5.9
Maximum power three phase (KVA)
7.3
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
230 / 400
Engine
Kohler 15LD440
Emissions Regulations
Stage 5
Engine rpm (rpm)
3000
Starting system
Elettrico
Engine capacity (cm³)
442
Number cylinders
1
Cooling
Air
Fuel tank capacity (L)
5
Consumption (L/h)
1.6 al 75% del carico
Running time (h)
3.1
Length (mm)
780
Width (mm)
520
Height (mm)
560
Dry weight (Kg)
106
Silenced
No
Super silenced
No
ATS Switch device
Optional
Voltage regulator
AVR (optional)
Engine manufacturer
Kohler
Details

TECNOGEN LD7500TE GENERATOR SET THREE-PHASE 7.3KVA

TECNOGEN LD7500TE Generator Set Three-phase 7.3KVA with single-phase outlets of 3 KW, equipped with a Kohler diesel engine running at 3000 RPM. The TECNOGEN LD7500TE generator is easy to use, compact, portable, and easy to maintain. The TECNOGEN LD7500TE Generator Set Three-phase 7.3KVA features electric start. This generator is ideal for both hobby and professional use, thanks to the reliable and efficient Kohler diesel engine and high-quality components.

Main features of TECNOGEN LD7500TE Generator Set Three-phase 7.3KVA:
Maximum 3-phase power: 5.8 KW
Maximum 3-phase power: 7.3 KVA
Fuel: Diesel
Voltage: 400V
Engine: Kohler 15LD440
Start: Electric
Length: 780 mm
Width: 520 mm
Height: 560 mm
Weight: 106 Kg


Why buy a TECNOGEN LD7500TE Generator Set Three-phase 7.3KVA?
First of all, they provide an effective solution for power failure problems during blackouts, both in domestic and business environments. The TECNOGEN LD7500TE generator is also used for construction sites and hobby applications. These professional generators are lightweight, compact, and durable, making them easy to transport, simple to use, and cost-effective to operate.

On the TECNOGEN LD7500TE generator, lifting hooks can be installed, making it convenient to move the generator with a crane or small hoist.

The full TECNOGEN range:
TECNOGEN generators are available in both single-phase and three-phase versions, with power ratings from 2.3 to 21 KVA MAX, equipped with gasoline or diesel engines, air-cooled, 3000 RPM, with electric and/or manual start with self-winding. Compact, simplified, and economical, they offer excellent value for price/performance/size and weight. Easily transportable thanks to their reduced dimensions due to their essential configuration, they are suitable for anyone who needs an economical power source, while still being assembled with top-quality components that guarantee absolute reliability. The TECNOGEN gasoline versions of the COMPACT line, thanks to the latest-generation Honda engines, comply with the noise directive 2000/14/CE.


Looking for a different model from the TECNOGEN LD7500TE Generator Set Three-phase 7.3KVA? Visit the section dedicated to terrestrial generators.
Images and technical data are non-binding.

Technical Sheet / Manuals
Related Accessories
List price
4.855,60 € tax incl.
3.980,00 € tax excl.
Discounted Price
2.865,78 € tax incl.
2.349,00 € tax excl.
