Capacity: 2330Wh (44.8V 52Ah)
Battery type: LiFePO4
Service life 3500 cycles at 80% - 6500 cycles at 60%
Management System MPPT Charge Control, BMS
Dimensions: 432x254.5x303.5 mm
Working temperature -20°C to 55°C
Weight: 24 Kg
Output Sockets
AC OUTPUT 120V/240V, 2200W (max 4400W)
USB-A OUTPUT Fast charging 3.0, 18W max (1pc) / 5V, up to 2.4A, 12W max per port (2pcs)
USB-C OUTPUT 5-20V, up to 5.0A, 100W max (1pce) / 5-20V, up to 1.5A, 30W max (1pce) /Double to 60W max (2pces)
CAR OUTPUT 12.6V 10A
DC 5521 OUTPUT 12.6V 4A
ANDERSON OUTPUT 12.6V 30A
LED 2W
INPUT SOCKETS
Charging socket
Solar:11V-75V, 12A, 600W max (basic model) /11V-75V, 15A, doubling to 20A 1200W max
(extra battery)
AC Socket For Charging 1800W max
The DABBSSON DBS2300 power station is the ideal solution for those who need a powerful and versatile power source for their adventures. With a maximum power output of 4400W and a capacity of 2330Wh, it can power a wide range of devices, including household appliances, power tools and electronic devices.
Advantages:
Maximum power of 4400W: enough to power most home appliances, such as portable refrigerators, gensets and power tools.
2330Wh capacity: enough to power electronic devices for several days.
Quick Charge 3.0: recharges the power station in about 1.5 hours.
30% higher energy density: results in significant efficiency and a reduction in the weight of the power station (24 kg).
Fewer contact points: fewer contact points, less heat generated, greater safety and less energy loss.
Uses:
The DABBSSON DBS2300 power station is ideal for a wide range of activities, including:
Camping and hiking: to power electronic devices and power tools.
Events and emergency situations: to provide power in the event of a blackout or emergency.
Remote work: to power computers and other electrical devices.
TECHNICAL DATA SHEET POLAR DABBSSON POWER STATION 2200W
Capacity: 2330Wh (44.8V 52Ah)
Battery type: LiFePO4
Service life 3500 cycles at 80% - 6500 cycles at 60%
Management System MPPT Charge Control, BMS
Dimensions: 432x254.5x303.5 mm
Working temperature -20°C to 55°C
Weight: 24 Kg
Output Sockets
AC OUTPUT 120V/240V, 2200W (max 4400W)
USB-A OUTPUT Fast charging 3.0, 18W max (1pc) / 5V, up to 2.4A, 12W max per port (2pcs)
USB-C OUTPUT 5-20V, up to 5.0A, 100W max (1pce) / 5-20V, up to 1.5A, 30W max (1pce) /Double to 60W max (2pces)
CAR OUTPUT 12.6V 10A
DC 5521 OUTPUT 12.6V 4A
ANDERSON OUTPUT 12.6V 30A
LED 2W
INPUT SOCKETS
Charging socket
Solar:11V-75V, 12A, 600W max (basic model) /11V-75V, 15A, doubling to 20A 1200W max
(extra battery)
AC Socket For Charging 1800W max
Looking for a portable battery or power station with different technical characteristics? HERE you can find the area dedicated to Portable Batteries and Uninterruptible Power Stations of specialised brands.
Non-binding images and technical data.
