TELWIN MAXIMA 190 SYNERGIC 230V

TELWIN MAXIMA 190 SYNERGIC 230V
search
  • TELWIN MAXIMA 190 SYNERGIC 230V
TELWIN
816088
Out Of Production

THIS PRODUCT IS OUT OF PRODUCTION

Technical features
Phase
Single phase
Frequency (Hz)
50 / 60
Voltage (V)
230
Efficiency (%)
87
Protection degree
IP23
Maximum permissible current (A)
32
No-load voltage (V)
52
Regulation current (A)
20 - 220
Diameter electrodes (mm)
1.6 - 3.2
Ø steel welding wire (mm)
0.6 - 1
Ø inox welding wire (mm)
0.8 - 1
Ø aluminium welding wire (mm)
0.8 - 1
Ø flux cored welding wire (mm)
0.8 - 1.2
Ø brazing wire (mm)
0.8 - 1
Current max (A)
180
Length (mm)
825
Width (mm)
360
Height (mm)
670
Weight (Kg)
21
Details
Technical Sheet / Manuals
icona_scheda

Scheda tecnica MAXIMA 230

(180.78k)
icona_scheda

Manuale MAXIMA 230

(17.2M)
Ask for availability
Add to wishlist
Download PDF
Ask a question
Product: TELWIN MAXIMA 190 SYNERGIC 230V
Offer on letterhead
Product: TELWIN MAXIMA 190 SYNERGIC 230V
Technical features
Phase
Single phase
Frequency (Hz)
50 / 60
Voltage (V)
230
Efficiency (%)
87
Protection degree
IP23
Maximum permissible current (A)
32
No-load voltage (V)
52
Regulation current (A)
20 - 220
Diameter electrodes (mm)
1.6 - 3.2
Ø steel welding wire (mm)
0.6 - 1
Ø inox welding wire (mm)
0.8 - 1
Ø aluminium welding wire (mm)
0.8 - 1
Ø flux cored welding wire (mm)
0.8 - 1.2
Ø brazing wire (mm)
0.8 - 1
Current max (A)
180
Length (mm)
825
Width (mm)
360
Height (mm)
670
Weight (Kg)
21
Details
Technical Sheet / Manuals
icona_scheda

Scheda tecnica MAXIMA 230

(180.78k)
icona_scheda

Manuale MAXIMA 230

(17.2M)
